Instrumentation

Instrumentation Work at HDPE

• End User:-OPaL
• Client:-SAMSUNG

Work Details:

Installation :-


• Cable Duct - 850 m
• Cable Tray - 11.5 Km
• Instrument Installation - 450
• Cable Lying - 88 Km
• Hookup of Impulse ( PI, PT, FT, LT, DPT ) - 222 Sets
• Calibration - 450 Nos.

TOTAL COST :- 1.68 CR

E & I Work at Gujarat Refinery, Vadodara.

• End User:-IOCL
• Client:-ENERGY INFRAPROJECTS Pvt. Ltd.

Work Details:

Installation :-


• Power Transformer - 1 Nos.
• Capacitor Bank - 2 Nos
• Cable Duct - 250 m
• Cable Tray - 11 Km
• Panels - 25 Nos.
• PA, Fire Telephone SystemInstrument Installation - 150
• Cable Lying - 88 Km
• Hookup of Impulse ( PI, PT, FT, LT, DPT ) - 222 Set
• Calibration - 450 Nos.
• Lighting Fixture - 256 Nos.

TOTAL COST :- 47 LAKH

Instrumentation Work for Nirma Ltd. Bhavnagar, Gujarat

• End User:-Nirma Ltd
• Client:-ICON Controls Pvt.

Work Details:

Installation :-


• TMFS - 1
• SetInstrument Installation ( LT, LG, LSH, TT and FT ) - 75 Nos.
• MCT Frame with Modules - 2 Set
• Civil Work - Lot
• Cable Lying - 32 Km
• Cable Tray - 2.2 Km .
• Earthing Work - 1 Km

TOTAL COST :- 18 LAKH

Electrical work for Wear House at HDPE Unit

• End User:-BPCL
• Client:-ICON Controls Pvt. Ltd.

Work Details:

Installation :-

• Panel - 30 Nos.
• Instruments Various Types - 650
• SS Tube + Impulse - 2 Km
• Yoke Support - 100 Nos.
• Conduit - 1 Km
• Cable Tray - 2.2 Km
• Cable Laying - 32 Km

TOTAL COST :- 10.5 LAKH
